250um 800m Per Roll Toothpaste Tube Pharmaceutical Industrial Use
High barrier alumi plastic laminated web for toothpaste tube with offset printing ★Usage: Kinds of toothpaste tube, food tube, pharmaceutical tube, industrial and cosmetic tube etc. ★Thickness and width ( μ: Thickness mm: width) Thickness: 200u/AL12; 220u/AL12; 250/AL12; 275/AL12; 258/AL20; 275/AL20...
toothpaste packaging
,tooth paste tube
High barrier alumi plastic laminated web for toothpaste tube with offset printing
★Usage:
Kinds of toothpaste tube, food tube, pharmaceutical tube, industrial and cosmetic tube etc.
★Thickness and width ( μ: Thickness mm: width)
Thickness: 200u/AL12; 220u/AL12; 250/AL12; 275/AL12; 258/AL20; 275/AL20; 325/AL9; 375/AL9; 425/AL9
Width: 45mm~800mm
★Material:
ABL—Alumi plastic lamination, aluminum as a barrier
★Feature:
Avirulence, hygiene, seal airtight, excellent barrier of air, water and fragrance. Easy to squeeze, sterilized with long shelf life, fine shading, fine burst-resist. Smooth in surface, rich colored, easy transfer, fulfill the different industry requirements.
- Our laminate machine is a world leading equipment form Germany Davis-Standard that ensures the stable quality of interlaminar strength. Delamination and uneven thickness issues can be reduced greatly.
- Our blow film machine is from Germany W-H, a world advanced equipment as well. Gel eye, burnt point and other quality problems can be improved effectively.
- Our resin material is from Dow and DuPont and other top brand names. The performance is more stable and very few impurities, which obviously improve the quality of film.
- Our sanitation of production is managed strictly, main workshop is full isolated and built according to GMP 100,000 level, so, our plant is first-rate in China.
- We have nearly 30 years of technical experience. Production technology stay ahead of other enterprises in China.
| Item | Standard | |||
| Appearance | 1.The defects of perforation,foreign material,unsymmetrical covering flux,lamination layer peeling off,obvious damnification,bubble,wrinkle and smudginess are not allowed. | |||
| 2.Printing in focus ,integrity,tinct uniformity and not aberration. | ||||
| Size Discrepance | Reel width:±1.0mm | |||
| Thickness Tolerance :1±7%um | ||||
| Peel Strength (N/15mm) | PE/PE-Copolymer>=6.0N/15mm | |||
| PE-Copolymer/AL>=6.0N/15mm | ||||
| AL/ Copolymer-PE>=6.0N/15mm | ||||
| Co-polymer-PE/PE>=6.0N/15mm | ||||
| Reel characterisics and packing | Reel winding outer layer outside | Core length same as the reel width Tolerance:+1mm | ||
| Reel dimensions | Reel length Meter/Reel.Tolerance:+ 2% | |||
| Joins | Tape on both sides, edge to edge(Butt joint) | |||
| Adhesive tape heat resistant red color, width 50mm. Number single reels max.3 joins,per reel average max2 joins per reel based on 800Meter/Reel. | ||||
| Identification | Reel label inside core, Indicate with Order, number/slit reel number/reel length/reel width/product date. One piece reel sample on out carton box. | |||
| Packing | Reels wrapped with polyethylene film and stack in wooden or plastic pallet, or as per customer requirement. | |||
